Description

The C117 Current Clamp is a high-performance 1,000 A transformer clamps. The round jaw shape and the uniformly-distributed winding guarantee accuracy and minimum phase difference.
It is equipped with an oscillating magnetic element adjustment system and a patented system for gradual assisted jaw opening.
Its 52 mm clamping capacity allows current measurements on most conductors on CAT III 600 V industrial and tertiary installations.

The excellent performance in terms of phase difference and linearity of this clamp equipped with a µmetal core fulfill the requirements for wattmeter applications.

Main features of the C117 Current Clamp:

  • Output signal: AC voltage
  • Output/input ratio: 1 mV / A AC
  • Output via isolated 4 mm female sockets
    Chauvin Arnoux C117 Current Clamp
