High-Resolution Compact Weighing for Industrial Precision
The Kern FKB Series offers precision bench scales with exceptional resolution up to 360,000 points. These compact yet robust units are ideal for applications requiring high accuracy in confined workspaces such as production, laboratory, or mechanical environments.
Equipped with a large stainless steel weighing plate, KUP port for flexible connectivity, and KCP protocol for remote control, the FKB is designed for industrial precision. With features such as programmable weighing units, pre-tare, and rapid stabilisation, it's suitable for a wide range of specialist uses.
Key Features
- High-Resolution Accuracy: Resolution up to 360,000 points, ideal for sensitive measurements
- Durable Construction: Robust plastic die-cast housing and stainless steel weighing platform
- KUP Interface Port: Supports optional adapters for USB, RS-232, WiFi, Bluetooth, Ethernet
- Remote Control Capability: Compatible with KCP for integration into automated systems
- Pre-Tare and Programmable Units: Manually subtract container weight or configure custom weighing units
- Levelling & Stability: Built-in level indicator and adjustable feet for consistent readings
Model Comparison
| Model | Capacity (kg) | Readability (g) | Reproducibility (g) | Linearity (g) |
|---|---|---|---|---|
| FKB 6K0.02 | 6 | 0.02 | 0.04 | ±0.1 |
| FKB 8K0.05 | 8 | 0.05 | 0.05 | ±0.15 |
| FKB 16K0.05 | 16 | 0.05 | 0.1 | ±0.25 |
| FKB 8K0.1 | 8 | 0.1 | 0.1 | ±0.3 |
| FKB 16K0.1 | 16 | 0.1 | 0.1 | ±0.3 |
| FKB 15K0.5 | 15 | 0.5 | 0.5 | ±1.5 |
| FKB 36K0.1 | 36 | 0.1 | 0.2 | ±0.5 |
| FKB 36K0.2 | 36 | 0.2 | 0.4 | ±1 |
| FKB 65K0.2 | 65 | 0.2 | 0.4 | ±1 |
| FKB 30K1 | 30 | 1 | 1 | ±3 |
| FKB 65K1 | 65 | 1 | 1 | ±3 |
Additional Information
- Display: Large backlit LCD, 25 mm digit height
- Weighing Pan Size: 340 × 240 mm (stainless steel)
- Dimensions (W×D×H): 350 × 390 × 120 mm
- Battery Option: Optional 4×AA battery pack, up to 20h runtime (not included)
- Operating Temperature: -10 °C to +40 °C
- Net Weight: Approx. 7 kg
