Ohaus Explorer EX Precision Balance
296511
Ohaus Explorer EX Precision Balance
296511
Advanced functionality with high accuracy and user-friendly design
The OHAUS Explorer® Precision Balances are engineered to provide accurate and reliable measurements for a wide range of applications in laboratory, industrial, and educational settings. With capacities ranging from 220 g to 10,200 g and readabilities as fine as 0.01 g, these balances combine cutting-edge technology with user-friendly features to enhance productivity and ensure compliance with GLP/GMP standards.
Key Features
- High Accuracy: Readabilities from 0.01 g ensure precise measurements for analytical and precision tasks.
- AutoCal™: Automatic internal calibration triggered by temperature or time changes to maintain consistent accuracy.
- Colour Touchscreen: 5.7-inch full-colour VGA touchscreen with user-controlled brightness for easy operation.
- Modular Design: Detachable terminal with a 1.5 m cable allows flexible positioning and reduces vibration interference.
- Touchless Sensors: Up to four programmable IR sensors enable hands-free operation to minimize contamination.
- Connectivity: Standard RS232 and USB ports; optional second RS232 or Ethernet interface available.
- GLP/GMP Compliance: Real-time clock, user management with password protection, and data output capabilities.
- Advanced Applications: Supports weighing, parts counting, percent weighing, checkweighing, dynamic weighing, formulation, density determination, peak hold, ingredient costing, pipette adjustment, and statistical quality control.
Model Suffixes Explained
- Models ending in ‘M’: Certified for legal-for-trade use (NTEP approved).
- Models ending in ‘/E’: External calibration versions, not trade-approved.
OHAUS Explorer Series – Model Comparison
| Model | Capacity (g) | Readability (g) | Pan Size (mm) | Calibration | Legal for Trade |
|---|---|---|---|---|---|
| EX10201 | 10,200 | 0.1 | 190 x 200 | AutoCal™ | No |
| EX10201M | 10,200 | 0.1 | 190 x 200 | AutoCal™ | Yes |
| EX10202 | 10,200 | 0.01 | 190 x 200 | AutoCal™ | No |
| EX10202M | 10,200 | 0.01 | 190 x 200 | AutoCal™ | Yes |
| EX1103 | 1,100 | 0.001 | 190 x 200 | AutoCal™ | No |
| EX1103M | 1,100 | 0.001 | 190 x 200 | AutoCal™ | Yes |
| EX2202 | 2,200 | 0.01 | 190 x 200 | AutoCal™ | No |
| EX2202/E | 2,200 | 0.01 | 190 x 200 | External | No |
| EX223 | 220 | 0.001 | 90 | AutoCal™ | No |
| EX223/E | 220 | 0.001 | 90 | External | No |
| EX4202 | 4,200 | 0.01 | 190 x 200 | AutoCal™ | No |
| EX4202/E | 4,200 | 0.01 | 190 x 200 | External | No |
| EX4202M | 4,200 | 0.01 | 190 x 200 | AutoCal™ | Yes |
| EX423 | 420 | 0.001 | 90 | AutoCal™ | No |
| EX423/E | 420 | 0.001 | 90 | External | No |
| EX423M | 420 | 0.001 | 90 | AutoCal™ | Yes |
| EX6201 | 6,200 | 0.1 | 190 x 200 | AutoCal™ | No |
| EX6201/E | 6,200 | 0.1 | 190 x 200 | External | No |
| EX6202 | 6,200 | 0.01 | 190 x 200 | AutoCal™ | No |
| EX6202/E | 6,200 | 0.01 | 190 x 200 | External | No |
| EX623 | 620 | 0.001 | 90 | AutoCal™ | No |
Additional Information
-
Calibration Types:
- AutoCal™: Automatic internal calibration
- External: Manual calibration with standard weights
- Legal for Trade: Models with the ‘M’ suffix are certified for trade use (NTEP approved)
- Pan Size: Most models feature a spacious 190 x 200 mm stainless steel platform
