Kern SXC Platform Scales
97600
Kern SXC Platform Scales
97600
IP68 Industrial Weighing with IoT Connectivity
The KERN SXC Series is a high-performance platform scale designed for demanding industrial and hygienic environments such as food processing, laboratories, and logistics. With full stainless steel construction, IP68 ingress protection, and up to four configurable data interfaces (RS-232, Ethernet, USB, WiFi, Bluetooth), it delivers precision and connectivity for modern operations.
The SXC range includes multi-range models with automatic resolution switching, bright backlit display, and optional alibi memory for secure documentation. Ideal for cleanrooms, production floors, and HACCP-compliant setups, the KERN SXC scales provide rugged durability, advanced features, and regulatory-ready performance.
Key Features
- Full Stainless Steel Build: Platform, load cell, and indicator rated to IP68 for dust and water protection
- Advanced Connectivity: Supports up to four interfaces including RS-232, Ethernet, USB, WiFi, Bluetooth
- Large Display: 48 mm digit height with bright backlight for visibility in all lighting conditions
- Multi-Range Function: Automatic dual-range switching for greater accuracy across loads
- Hygienic Design: Ideal for food and pharma sectors with easy-clean surfaces
- Alibi Memory (Optional): Paperless storage of verified weighing results for audit compliance
- Accessories Available: Stands, printers, roller conveyors, signal lights, ESD protection, and more
Model Comparison
| Model | Capacity (kg) | Readability (g) | Pan Size (mm) |
|---|---|---|---|
| SXC 6K-4 | 6 | 0.5 | 300 × 240 |
| SXC 10K-3 | 15 | 1 | 300 × 240 |
| SXC 10K-3L | 15 | 1 | 400 × 300 |
| SXC 30K-3 | 30 | 2 | 400 × 300 |
| SXC 30K-3L | 30 | 2 | 500 × 400 |
| SXC 60K-3 | 60 | 5 | 400 × 300 |
| SXC 60K-3L | 60 | 5 | 500 × 400 |
| SXC 100K-2 | 150 | 10 | 500 × 400 |
| SXC 100K-2L | 150 | 10 | 650 × 500 |
| SXC 300K-2 | 300 | 20 | 650 × 500 |
Additional Information
- Temperature Range: -10°C to +40°C.
- Display Device: IP68 stainless steel, 48 mm digits, cable length approx. 3 m
- Available Verification: Optional calibration and conformity assessment (NAWI 2014/31/EU)
- Use Cases: Industrial weighing, food production, washdown zones, pharmaceutical packaging
