The 40mm bottom entry general purpose pressure gauge is designed for light-duty hydraulic and pneumatic applications. It offers reliable measurement performance for everyday use in less demanding environments.

Available in ranges from -1 bar to 28 bar (300 psi), supplied with a 1/8" BSPT thread as standard. An optional calibration certificate can also be provided.

Click here to add a connection adapter

Case: Black enamelled steel
Bezel: Push fit window
Window: Acrylic
Connection: Brass
Sensitive Element: Brass
Movement: Brass
Joints: Soldered silver alloy
Pointer: Black aluminium
Dial: Stoved enamel on aluminium
Accuracy: Class 2.5
Scale: Dual psi (outer) + bar (inner).
