Heavy-duty single point load cell for high-capacity platform and industrial scale systems

The Laumas AR Series is a high-capacity single point load cell engineered for demanding platform scale and industrial weighing applications. Constructed from anodised aluminium and rated to IP65, it ensures long-term stability and resistance to harsh environments. The AR Series is OIML R60 C3 certified and supports optional certifications for explosive zones and legal-for-trade use worldwide.

Key Features

• High Accuracy: OIML R60 C3 certified
• Capacity Range: 500 kg, 1000 kg
• Material: Anodised aluminium alloy
• Protection Rating: IP65 – dust-tight and resistant to water spray
• Platform Compatibility: Suitable for heavy-duty platform and floor scales
• Output Signal: 2 mV/V ±10%
• Cable: 4-wire shielded, 1.5 m length
• Certifications: CE, UKCA, EAC, and UK Legal for Trade

Available Models

Certifications on Request

• ATEX II 1G 2D – suitable for gas zones (0/1/2) and dust zones (21/22)
• IECEx – for international hazardous area compliance
• OIML R60 C4 / C5 – higher-accuracy versions available
• EAC Ex – for explosive zones in Eurasian markets
• Ex NEPSI – compliant with Chinese explosion-proof requirements
• NTEP – legal-for-trade in the United States
