Hygienic Stainless Steel Junction Boxes – IP68 Rated for Sanitary Applications

The Laumas CDG 3A is a high-grade hygienic junction box designed for food, pharmaceutical, and cleanroom applications. Made from AISI 304 stainless steel with a cylindrical body, it ensures easy sanitization and compliance with 3-A SSI hygienic standards. The CDG 3A supports up to 4 load cells with 4 or 6-wire connection and is sealed with a blue hygienic cable gland for up to 7 cables. IP68-rated, it's suitable for washdown environments, with two included hygienic M5 screws for optimal sealing.

Key Features

• Material: AISI 304 stainless steel body
• Design: Cylindrical, hygienic shape for full washdown compliance
• Protection: IP68 for use in aggressive cleaning environments
• Cable Gland: Blue hygienic design, accommodates up to 7 cables
• Load Cell Support: Connect up to 4 load cells (4 or 6 wires)
• Sealing Hardware: 2x M5 hygienic screws with seals included
• Operating Temp: –20 °C to +60 °C
• Certifications: 3-A SSI hygienic compliance (RPSCQC approved)

Models Available

• CDG4E03A: Equalization board
• CDG43A: Parallel connection board

Certifications

• UKCA: CE equivalent for UK compliance
• 3-A SSI: Hygienic design certified for food and pharma environments

Dimensions (mm)

• Height: 143.4 mm
• Base Diameter: Ø92 mm
• Body Diameter: Ø68 mm
• Mounting Holes: 2 × Ø5.5 mm
