TLB Analogue Weight Transmitter

Q: What is a load cell signal converter used for?

Load cell signal converters transform load cell outputs into signals suitable for PLCs and control systems.

Q: How accurate are analogue load cell transmitters?

Analogue transmitters provide highly stable and accurate load cell signal conversion.

Q: Where are analogue load cell converters typically installed?

Analogue converters are commonly installed where analogue PLC inputs are used.

Q: Why choose an analogue weight transmitter?

Analogue transmitters provide simple integration with analogue PLC and control inputs.

TLB Analogue Weight Transmitter Overview

The Laumas TLB Analogue Weight Transmitter converts load cell signals into usable analogue outputs for industrial weighing systems. It is designed for applications requiring reliable signal conditioning, weight conversion and integration with control equipment.

Suitable for tanks, hoppers, platforms and process weighing systems, the TLB Analogue provides practical load cell signal conversion for PLCs, displays and monitoring systems.

Model: TLB

Quantity:

£244.00

View Technical Data Sheet (PDF)

Laumas TLB Analogue Weight Transmitter

£244.00

Learn more

Product specification

Compare model specifications.

Learn More

Technical Specification

Output

16 bit = 65535 divisions. 0÷20 mA; 4÷20 mA (up to 300R) 0÷10 V; 0÷5 V; ±10 V; ±5 V (min 10kR)

Input Range

±39 mV

Number Of Load Cells

1

Excitation Voltage

5 VDC / 120 mA

Accuracy

<0.01% full scale

Digital Inputs

2 x 5 to 24 VDC PNP

Relay Outputs

3 x 115 VAC / 150 mA (max)

Mounting

DIN Rail

Serial Connection

RS485

Analogue / Digital Converter

24 bit (16000000 points) - 4.8 kHz

OIML Certification

OIML R76:2006, class III, 3x10000 divisions, 0.2uV/VSI / OIML R61 - WELMEC Guide 8.8:2011 (MID)

Learn more

Applications

Industrial Weighing Systems

Suitable for industrial tank weighing systems requiring analogue output signals.

Hopper & Silo Monitoring

Used for hopper and silo monitoring where analogue output integration is required.

PLC Based Process Control

Provides weighing data to PLC-controlled production and process systems.

Machine Builder Integration

Ideal for machine builders integrating weighing functions into industrial equipment.

Features

Load Cell Signal Conversion

Converts load cell signals into stable analogue outputs for industrial control systems.

High Accuracy Signal Conditioning

Provides stable and accurate conversion of load cell signals for process control systems.

Industrial Process Integration

Integrates load cell signals into industrial weighing and process control systems.

Reliable Industrial Weighing Data

Provides reliable weighing data for process control, monitoring and automation applications.

FAQs

What is a load cell signal converter used for?

Load cell signal converters transform load cell outputs into signals suitable for PLCs and control systems.

How accurate are analogue load cell transmitters?

Analogue transmitters provide highly stable and accurate load cell signal conversion.

Where are analogue load cell converters typically installed?

Analogue converters are commonly installed where analogue PLC inputs are used.

Why choose an analogue weight transmitter?
