Laumas TFCFSB Load Cell Mounting Kit
Laumas TFCFSB Load Cell Mounting Kit
The Laumas TFCFSB is a load cell mounting kit for industrial weighing installations using Laumas FCOL and FCK bending beam load cells. It is intended for applications up to 300 kg and provides a practical mechanical interface between the load cell and the supporting structure.
Correct mounting is critical in any weighing system. The TFCFSB uses an AISI 304 stainless steel construction with a compression joint made from AISI 304 stainless steel and rubber. This arrangement helps compensate for minor misalignment between support plates, reducing installation sensitivity where the supporting structure is not perfectly parallel.
The kit is particularly relevant for engineers, OEMs and system integrators building or maintaining compact weighing assemblies. It gives a repeatable mounting arrangement for compatible bending beam load cells and supports stable load introduction when installed as part of a correctly designed weighing structure.
Technical Buying Context
- Manufacturer: Laumas
- Model: TFCFSB
- Load cell type: Bending beam
- Compatible Laumas load cells: FCOL and FCK
- Application range: Up to 300 kg
- Material: AISI 304 stainless steel with stainless steel and rubber compression joint
- Kit supply: Mounting kit only; load cell not included
When specifying the TFCFSB, the complete weighing arrangement should be checked rather than the mounting kit in isolation. Confirm the load cell model, total system capacity, number of supports, structural layout and any forces introduced during filling, discharge, cleaning or maintenance. GNW can supply the TFCFSB as a component for industrial weighing systems where Laumas FCOL or FCK bending beam load cells are already selected or being specified.
Installation Considerations
The mounting kit should be fitted in accordance with the weighing system design and the relevant Laumas installation information. During installation, care should be taken to avoid introducing side loads, distortion or mechanical strain into the load cell. For replacement work, match the existing mounting arrangement and confirm compatibility before changing components.
Learn more
Product specification
Compare model specifications.
| Model | TFCFSB |
|---|---|
| Use With | FCK, FCOL |
| Max Static Load | 300 kg |
Learn more
Applications
Features
FAQs
Which load cells are compatible with the TFCFSB mounting kit?
Why is a dedicated bending beam mounting kit important?
Where is the TFCFSB mounting kit typically used?
Why is a dedicated bending beam mounting kit preferable to a fabricated bracket?
A dedicated bending beam mounting kit is designed to manage load paths correctly, reducing side loads and installation stresses that can affect weighing accuracy.
