Laumas TFCGP Load Cell Mounting Kit

The Laumas TFCGP load cell mounting kit is a mechanical mounting assembly for FCOL and FCK bending beam load cells in light industrial weighing systems. It is intended for applications up to 300 kg and is commonly specified for small tanks, hoppers, platforms and similar structures where the load cell needs a controlled and repeatable mounting arrangement.

Rather than fixing a bending beam load cell directly into a fabricated structure, the TFCGP provides a defined interface between the load cell and the supporting frame. The kit is made from AISI 304 stainless steel and includes an upper plate with a compression joint in AISI 304 stainless steel and rubber. This arrangement helps accommodate support plate misalignment, which can otherwise introduce unwanted side loads or inconsistent load transfer.

For engineers and system integrators, the TFCGP is particularly relevant where mechanical installation quality has a direct effect on weighing performance. Correct mounting helps the load cell work within its intended loading direction and reduces avoidable stresses during assembly, handling and commissioning. A locking screw is provided to help protect the load cell during transport and installation.

Key Technical Context

• Product type: load cell mounting kit for bending beam load cells.
• Compatible load cell series: Laumas FCOL and FCK.
• Application range: up to 300 kg.
• Construction: AISI 304 stainless steel with stainless steel and rubber compression joint.
• Typical installations: small tanks, hoppers, platforms and light industrial weighing structures.

The TFCGP should be selected as part of the complete weighing assembly, taking account of the number of supports, vessel or platform geometry, load distribution, installation environment and the required load cell capacity. It is intended for systems with at least three supports. Where replacing an existing mounting kit, confirm the installed load cell model and mechanical configuration before ordering.

GNW Instrumentation supplies the Laumas TFCGP for OEM equipment builders, maintenance teams and weighing system integrators requiring a stainless mounting solution for FCOL and FCK bending beam load cell installations.
