Kern CKE Counting Scales - GNW Instrumentation

Kern CKE Counting Scales

Kern CKE counting scales provide straightforward piece counting and weighing for stock control, order picking, production monitoring and quality-control applications. The range combines strain-gauge weighing technology with a clear LCD and a graphic control panel that guides operators from tare and reference quantity through to the calculated piece count.

Automatic reference-weight optimisation improves the average piece-weight value during counting, while a dedicated key allows users to switch between counting and weighing modes. The KERN Universal Port and KERN Communication Protocol provide options for transferring data to and communicating with compatible external equipment.

View Accessories

Why is calibration important?

Quantity:

£595.85

Tax excluded. Shipping calculated at checkout

Estimated delivery: Approx. 5 working days.

Need Help? Ask a Question

View Technical Data Sheet (PDF)

Kern Kern CKE Counting Scales

£595.85

Learn more

Product specification

Compare model specifications.

Model	CKE 16K0.05	CKE 16K0.1	CKE 3600-2	CKE 360-3	CKE 36K0.1	CKE 65K0.2	CKE 6K0.02	CKE 8K0.05
Capacity	16 kg	16 kg	3.6 kg	360 g	36 kg	65 kg	6 kg	8 kg
Readability	0.05 g	0.1 g	0.01 g	0.001 g	0.1 g	0.2 g	0.02 g	0.05 g
Repeatability	0.1 g	0.1 g	0.01 g	0.001 g	0.2 g	0.4 g	0.04 g	0.05 g
Legal For Trade	No	No	No	No	No	No	No	No
Platform Size	340 mm x 240 mm	340 mm x 240 mm	150 mm x 170 mm	82 mm	340 mm x 240 mm	340 mm x 240 mm	340 mm x 240 mm	340 mm x 240 mm
Units	kg, lb, PCS	kg, lb, PCS	g, wt, ozt, ct, lb, oz, to	g, gn, wt, ozt, ct, lb, oz, to	g, gn, wt, ozt, ct, lb, oz, to	g, gn, wt, ozt, ct, lb, oz, to	kg, g, t, gn, wt, ozt, ct, mo, lb, oz, m	kg, g, t, gn, wt, ozt, ct, mo, lb, oz, m

Learn more

Applications

Inventory Counting

Useful for stock taking where quantities of parts or components need to be counted efficiently.

Order Picking

Supports accurate piece counts when preparing items for dispatch or internal supply.

Production Monitoring

Helps production teams check quantities during series production and routine monitoring.

Quality Control

Suitable for count-based checks within industrial quality control processes.

Features

Intuitive Operation

The graphic control panel guides users through counting steps with minimal training.

Accurate Counting

Laboratory accuracy and high counting resolution support dependable piece counting.

Reference Optimisation

Automatic reference weight optimisation gradually improves the average piece weight value.

Flexible Connectivity

The KERN Universal Port supports external interface adapters for data exchange and control commands.

FAQs

Is the Kern CKE Counting Scale suitable for untrained users?

Yes, the self-explanatory graphic control panel is designed to reduce learning time and help avoid operating errors.

Can the CKE be used for both counting and weighing?

Yes, it can change from counting mode to weighing mode at the touch of a key.

Does this counting scale support data connection options?

Yes, the KERN Universal Port allows connection of suitable KUP interface adapters such as RS-232, USB, Bluetooth, WiFi or Ethernet.

What display and weighing system does the CKE use?

The Kern CKE uses a strain gauge weighing system and an LCD display.

Need more help? Contact our sales team.
