Standard Bench Scales – Legal-For-Trade Precision with IP68 Stainless Indicator
The OHAUS Defender 5000 i-D52XW Series offers high-performance bench scales built for demanding industrial use. These models feature a durable stainless steel platform, IP68-rated TD52XW stainless steel indicator, and dual-range precision ideal for legal-for-trade and non-trade applications.
With smart features like SmarText™ 3.0, fast stabilization under 1 second, multi-mode support, and up to 50,000 item library capacity, these scales are ideal for complex industrial operations. Certified models are OIML/EC-approved for regulated environments.
Key Features
- Durable Industrial Build: Stainless steel platform, powder-coated steel frame, and IP68-rated indicator
- Dual-Range Readability: Enhanced precision that auto-adjusts based on load weight
- SmarText™ 3.0 Display: Intuitive user interface with large dot matrix LCD and on-screen guidance
- Multifunctional Modes: Parts Counting, Percent Weighing, Dynamic Hold, Checkweighing, Filling, and more
- Data Storage & Traceability: 50,000 item memory, 1,000 user profiles, Micro SD card and Alibi memory support
- Versatile Connectivity: Standard RS232 + optional Ethernet, USB Host/Device, WiFi/Bluetooth, analog, and digital I/O
Model Comparison
| Model | Capacity (kg) | Readability (g) | Certified Model | Certified Readability | Pan Size (mm) |
|---|---|---|---|---|---|
| D52XW6RQDR1-GB | 3/6 | 0.2/0.5 | D52XW6RQDR1-M | 1/2 | 305 × 305 |
| D52XW15RQDR1-GB | 6/15 | 0.5/1 | D52XW15RQDR1-M | 2/5 | 305 × 305 |
| D52XW15RQDL2-GB | 15/30 | 1/2 | D52XW15RQDL2-M | 5/10 | 400 × 400 |
| D52XW30RQDL2-GB | 30/60 | 2/5 | D52XW30RQDL2-M | 10/20 | 400 × 400 |
| D52XW60RQDL2-GB | 60/150 | 5/10 | D52XW60RQDL2-M | 20/50 | 400 × 400 |
| D52XW60RQDX2-GB | 60/150 | 5/10 | D52XW60RQDX2-M | 20/50 | 500 × 500 |
| D52XW150RQDX2-GB | 150/300 | 10/20 | D52XW150RQDX2-M | 50/100 | 500 × 500 |
| D52XW60RQDV3-GB | 60/150 | 5/10 | D52XW60RQDV3-M | 20/50 | 610 × 610 |
| D52XW150RQDV3-GB | 150/300 | 10/20 | D52XW150RQDV3-M | 50/100 | 610 × 610 |
| D52XW300RQDV3-GB | 300/600 | 20/50 | D52XW300RQDV3-M | 100/200 | 610 × 610 |
| D52XW150RTDV3-GB | 150/300 | 10/20 | D52XW150RTDV3-M | 50/100 | 600 × 800 |
| D52XW300RTDV3-GB | 300/600 | 20/50 | D52XW300RTDV3-M | 100/200 | 600 × 800 |
| D52XW600RTDV3-GB | 300/600 | 20/50 | D52XW600RTDV3-M | 100/200 | 600 × 800 |
| D52XW6RQDR5-GB | 3/6 | 0.2/0.5 | D52XW6RQDR5-M | 1/2 | 305 × 305 |
| D52XW15RQDR5-GB | 6/15 | 0.5/1 | D52XW15RQDR5-M | 2/5 | 305 × 305 |
| D52XW15RQDL5-GB | 15/30 | 1/2 | D52XW15RQDL5-M | 5/10 | 400 × 400 |
| D52XW30RQDL5-GB | 30/60 | 2/5 | D52XW30RQDL5-M | 10/20 | 400 × 400 |
| D52XW60RQDL5-GB | 60/150 | 5/10 | D52XW60RQDL5-M | 20/50 | 400 × 400 |
| D52XW60RQDX5-GB | 60/150 | 5/10 | D52XW60RQDX5-M | 20/50 | 500 × 500 |
| D52XW150RQDX5-GB | 150/300 | 10/20 | D52XW150RQDX5-M | 50/100 | 500 × 500 |
Additional Information
- Display: 256 × 80 dot matrix LCD, white LED backlight, with intuitive menu navigation
- Stabilization Time: Results in less than 1 second
- Battery Option: Rechargeable Li-ion battery with up to 20 hours of operation (optional)
- Operating Range: -10°C to 40°C
- Certifications: OIML R76, CE, FCC, CSA, RCM compliant
