Ohaus Navigator portable balances are designed for general weighing across laboratories, production areas, warehouses and educational facilities. Their robust construction, straightforward controls and fast stabilisation support efficient day-to-day use, while enhanced overload protection helps protect the weighing system in demanding working environments.

The range includes different capacities, readabilities and platform formats for samples, components, ingredients and packaged items. Battery operation and a portable, stackable design allow the balance to be moved between workstations, while multifunction weighing modes provide additional flexibility for applications such as counting, percentage weighing, checkweighing and display hold where supported by the selected model.

View Accessories
Model: NV222

Model
Calibration Certificate: No

Calibration Certificate
Sale price£280.25
View Technical Data Sheet (PDF)

Learn more

Product specification

Compare model specifications.

Model NV222 NV422 NV622 NV221 NV621 NV1201 NV2201 NVT2201 NVT4201 NVT6201 NVT2200 NVT6200 NVT12000 NVT22000 NVT1601M NVT3200M NVT6400M NVT16000M NV223 NV2202 NVT10201
Capacity 220 g 420 g 620 g 220 g 620 g 1.2 kg 2.2 kg 2.2 kg 4.2 kg 6.2 kg 2.2 kg 6.2 kg 12 kg 22 kg 1.6 kg 3.2 kg 6.4 kg 16 kg 220 g 2.2 kg 10.2 kg
Readability 0.01 g 0.01 g 0.01 g 0.1 g 0.1 g 0.1 g 0.1 g 0.1 g 0.1 g 0.1 g 1 g 1 g 1 g 1 g 0.5 g 1 g 2 g 5 g 1 mg 0.01 g 0.1 g
Repeatability 0.01 g 0.02 g 0.02 g 0.1 g 0.1 g 0.1 g 0.1 g 0.1 g 0.2 g 0.2 g 1 g 1 g 1 g 1 g 0.5 g 1 g 2 g 5 g 2 mg 0.02 g 0.2 g
Legal For Trade No No No No No No No No No No No No No No Yes Yes Yes Yes No No No
Platform Size 145 mm 145 mm 145 mm 144 mm x 190 mm 144 mm x 190 mm 144 mm x 190 mm 144 mm x 190 mm 174 mm x 230 mm 174 mm x 230 mm 174 mm x 230 mm 174 mm x 230 mm 174 mm x 230 mm 174 mm x 230 mm 174 mm x 230 mm 174 mm x 230 mm 174 mm x 230 mm 174 mm x 230 mm 174 mm x 230 mm 93 mm 144 mm x 190 mm 174 mm x 230 mm
Units ct / Gr / g / N / oz / ozt / dwt ct / Gr / g / N / oz / ozt / dwt ct / Gr / g / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / N / oz / ozt / dwt ct / Gr / g / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / g / kg ct / g / kg ct / g / kg ct / g / kg ct / Gr / g / N / oz / ozt / dwt ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz ct / Gr / g / kg / N / oz / ozt / dwt / lb / lb:oz

Learn more

Applications

Routine Laboratory Weighing

Designed for routine sample, component and material weighing across laboratories, production areas and educational facilities requiring fast, straightforward operation.

Component and Parts Counting

Parts counting and percentage functions help determine component quantities, compare samples and support repetitive production or inventory tasks.

Packing and Order Preparation

Fast weighing and multifunction modes support order preparation, packing checks and routine warehouse handling of components, samples and finished goods.

Education and Training

Portable construction and robust overload protection suit training environments where balances are frequently moved and used by multiple operators.

Features

Fast Routine Weighing

Rapid stabilisation and robust overload protection support efficient day-to-day weighing across laboratories, warehouses and production workstations.

Four-Times Overload Protection

An overload protection system designed to withstand loads up to four times the rated capacity helps safeguard the balance during busy everyday use.

Parts Counting and Checkweighing

Optional Communication Interfaces

Optional Communication Interfaces

Optional RS-232, USB or Ethernet interfaces allow results to be transferred to compatible printers, computers or data-management systems.
