Dual Optical SCI/SCE • LED/UV • Portable & Precise

High-Precision Colour Measurement for Quality Control & Industry Standards

The Sauter JCS Colour Spectrometer is designed for accurate and versatile colour analysis across textiles, printing, ceramics, cosmetics, and plastics. This professional instrument allows comprehensive characterisation of colours with or without gloss, ensuring adherence to national and international colour standards.

Equipped with dual optical paths, the JCS records both SCI (Specular Component Included) and SCE (Specular Component Excluded) spectra simultaneously. Its geometric optical D/8° design and LED/UV light source enable high-performance measurement on a wide range of materials and finishes. Portable, robust, and user-friendly, it delivers lab-grade results in seconds.

Key Features

• Dual Optical Paths: Simultaneous SCI and SCE spectrum capture for comprehensive colour characterisation
• Geometric Optics: D/8° design suitable for diverse materials and surface types
• Adjustable Observation Angles: 2° and 10° standard observation angles selectable
• Multiple Aperture Sizes: Choose MAV (Ø 8–10 mm), SAV (Ø 4–5 mm), or LAV (1×3 mm)
• LED & UV Light Source: Supports fluorescence measurements and consistent illumination
• Onboard Calibration: Protected integrated white reference panel ensures long-term accuracy
• Portable & Durable: Compact, shockproof, and dustproof design for field and lab use
• Touch Display Interface: Colour screen with intuitive controls for seamless operation

Model Options

Additional Specifications

• Colour Metrics: Supports WI (ASTM, CIE/ISO, AATCC, Hunter), YI, Munsell, Mt index, colour fastness, coverage, and more
• Accuracy: Displayed to 0.01 of max value
• Repeatability: Standard deviation: 0.08
• Power: LED and UV light source
• Data Interface: USB as standard
• Dimensions: 188 × 94 × 68 mm
• Weight: Approx. 0.30 kg
