160mm Bottom Entry General Purpose Pressure Gauge


Choose this 160 mm dry gauge where the dial needs to be read from further away, such as on a plant line or manifold.

The connection is underneath the dial for upright fitting on compatible pipework or an equipment port.

Range: -1/0 bar & -30/0 inHg

Range

Thread Size: 3/8'' BSP

Thread Size

Calibration Certificate: No

Calibration Certificate

Where optional calibration is selected, the calibration certificate is issued by GNW Instrumentation. What’s included?

Why is calibration important?
Sale price$66.00

Tax excluded. Shipping calculated at checkout

Estimated delivery: Approx. 2–3 working days.

Ask GNW a Question

Need help choosing the correct instrument? Send our team your question.

Product: 160mm Bottom Entry General Purpose Pressure Gauge

Learn More

Technical Specification

Size
160mm
Case
Black enameled steel
Bezel
Removable 304 Stainless Steel
Wetted Parts
Brass
Window
Instrument Glass
Dial
Aluminium - Dual Scale
Pointer
Black Aluminium
Accuracy
Class 1 (±1% of span)
Connection Size
3/8'' BSP, 1/2'' BSP, 1/2'' NPT, 1/2'' BSPT
Connection Orientation
Bottom Entry

Optional Calibration & Certification

Add an optional calibration certificate to document your instrument’s performance before use and support your quality records. Find out below what testing is included and what your certificate provides.

Who issues the certificate? Where optional calibration is selected, the calibration certificate is issued by GNW Instrumentation.
What testing is included? The pressure gauge is compared with traceable reference pressure equipment at selected test points appropriate to its measuring range. The actual calibration points are recorded on the certificate.
What does the certificate report? The certificate identifies the instrument and reference equipment, and reports the applied pressures, instrument indications and measurement errors. Results relate to the instrument as calibrated.

Learn more

Applications

Main Line Pipework

Designed for installation on main pipelines where high visibility is required.

Water Treatment

Used in water treatment systems for reliable pressure monitoring.

Process Industries

Used in process industries where pressure control is critical.

Testing Systems

Suitable for calibration and testing systems where accurate readings are needed.

Features

Dial

Extra-large 160mm dial delivers outstanding readability for industrial monitoring applications.

Configuration

Bottom entry configuration for installation into pipework where high visibility is required.

Construction

Black enameled steel case ensures long-lasting durability and resistance to wear in general-purpose use.

Accuracy

The stated error limit is ±1% of the full pressure span.
