50mm Back Entry All Stainless Steel Pressure Gauge


A 50 mm dry stainless steel gauge for a machine face where space is tight and the process requires stainless steel wetted parts.

The connection is centred behind the dial. When replacing a gauge, check the thread and clearance behind the panel. The wetted parts are 316L stainless steel. Check they suit the gas or liquid in your system.

Range: -1/0 bar to 0/+2 bar & -30/0 inHg to 0/+30 psi

Range

Thread Size: 1/8" BSP

Thread Size

Calibration Certificate: No

Calibration Certificate

Where optional calibration is selected, the calibration certificate is issued by GNW Instrumentation. What’s included?

Why is calibration important?
Sale price£57.72

Tax excluded. Shipping calculated at checkout

Estimated delivery: Approx. 2–3 working days.

Ask GNW a Question

Need help choosing the correct instrument? Send our team your question.

Product: 50mm Back Entry All Stainless Steel Pressure Gauge

Learn More

Technical Specification

Size
50mm
Case
304 Stainless Steel
Bezel
Removable 304 Stainless Steel
Wetted Parts
316L Stainless Steel
Window
Polycarbonate Plastic
Dial
Aluminium - Dual Scale
Pointer
Black Aluminium
Accuracy
1.6%
Connection Size
1/8" BSP, 1/4" BSP, 1/4" NPT, 1/4" BSPT
Connection Orientation
Centre Back Entry

Optional Calibration & Certification

Add an optional calibration certificate to document your instrument’s performance before use and support your quality records. Find out below what testing is included and what your certificate provides.

Who issues the certificate? Where optional calibration is selected, the calibration certificate is issued by GNW Instrumentation.
What testing is included? The pressure gauge is compared with traceable reference pressure equipment at selected test points appropriate to its measuring range. The actual calibration points are recorded on the certificate.
What does the certificate report? The certificate identifies the instrument and reference equipment, and reports the applied pressures, instrument indications and measurement errors. Results relate to the instrument as calibrated.

Learn more

Applications

Machine Fascia Pressure Indication

The rear connection layout works well on machine fronts where a compact 50mm gauge is needed for local pressure checks.

OEM Skid Instrumentation

Packaged plant and skid builders can use the compact dial size where space is limited but a local pressure gauge is still required.

Stainless Steel Process Lines

316L stainless steel wetted parts support use on compatible services where stainless wetted materials are specified by the plant standard.

Maintenance Replacement Gauges

The 50mm back entry format is a practical replacement option for existing installations with the same connection orientation and material requirements.

Features

Dial

The 50mm dial provides compact local pressure indication on machinery, panels and skid-mounted equipment where space is limited.

Configuration

The back entry connection positions the process connection behind the gauge, supporting neat installation on equipment faces and panel layouts.

Construction

A 304 stainless steel case with 316L stainless steel wetted parts provides stainless construction for industrial duties where compatible materials are required.

Accuracy

This gauge is specified at 1.6% accuracy.
