63mm Back Entry All Stainless Steel Pressure Gauge


A dry stainless steel gauge with a 63 mm dial for a machine face where the process connection runs behind the dial.

The connection is centred behind the dial. When replacing a gauge, check the thread and clearance behind the panel. The wetted parts are 316L stainless steel. Check they suit the gas or liquid in your system.

Range: -1/0 bar to 0/+1 bar & -30/0 inHg to 0/+15 psi

Range

Thread Size: 1/4" BSP

Thread Size

Calibration Certificate: No

Calibration Certificate

Where optional calibration is selected, the calibration certificate is issued by GNW Instrumentation. What’s included?

Why is calibration important?
Sale price£49.95

Tax excluded. Shipping calculated at checkout

Estimated delivery: Approx. 2–3 working days.

Ask GNW a Question

Need help choosing the correct instrument? Send our team your question.

Product: 63mm Back Entry All Stainless Steel Pressure Gauge

Learn More

Technical Specification

Size
63mm
Case
304 Stainless Steel
Bezel
Removable 304 Stainless Steel
Wetted Parts
316L Stainless Steel
Window
Polycarbonate Plastic
Dial
Aluminium - Dual Scale
Pointer
Black Aluminium
Accuracy
Class 1.6 (±1.6% of span)
Connection Size
1/4" BSP, 1/4" BSPT, 1/4" NPT, 1/8" BSP, 1/8" BSPT, 1/8" NPT
Connection Orientation
Centre Back Entry

Optional Calibration & Certification

Add an optional calibration certificate to document your instrument’s performance before use and support your quality records. Find out below what testing is included and what your certificate provides.

Who issues the certificate? Where optional calibration is selected, the calibration certificate is issued by GNW Instrumentation.
What testing is included? The pressure gauge is compared with traceable reference pressure equipment at selected test points appropriate to its measuring range. The actual calibration points are recorded on the certificate.
What does the certificate report? The certificate identifies the instrument and reference equipment, and reports the applied pressures, instrument indications and measurement errors. Results relate to the instrument as calibrated.

Learn more

Applications

Panel-Mounted Pressure Indication

Back entry configuration is well suited to instrument panels and control cabinets requiring a compact 63mm front display.

OEM Machinery and Skid Assemblies

Equipment builders can specify this all stainless steel pressure gauge where rear connection and stainless wetted parts are required within a compact assembly.

Industrial Process Monitoring

316L stainless steel wetted parts make the gauge a practical choice for compatible process media requiring stainless contact materials.

Maintenance Replacement Gauges

The 63mm size and back entry layout support replacement work on existing machinery where the mounting arrangement matches the original gauge.

Features

Dial

The 63mm dial provides a compact indication format for machinery, panels and local pressure monitoring points where space is limited.

Configuration

The back entry connection suits rear-mounted installations, including control panels, skids and equipment housings requiring a neat front-facing display.

Construction

A 304 stainless steel case supports use in industrial environments, while 316L stainless steel wetted parts provide stainless contact surfaces for compatible media.

Accuracy

The stated error limit is ±1.6% of the full pressure span.
